Deck Oven Sveba Dahlen

The D-Series consists of robust, reliable and efficient deck ovens. This series is flexible with a wide range of options, allowing the oven to be tailored to the specific needs of the bakery for high-quality results.

Modular Design

Even Heat Distribution

Reliable & Robust

Highly Customizable

Request Wholesale Quote

Model & Technical	D1	D2	D2E	D3	D4
Max. tray size (mm)	600 x 800	2 x 470 x 800	2 x 600 x 800	3 x 470 x 800	4 x 470 x 800 / 3 x 600 x 800
Internal measurement (mm)	635 x 820	950 x 820	1265 x 820	1580 x 820	1895 x 820
Baking surface (mm)*	630 x 804	945 x 804	1260 x 804	1575 x 804	1890 x 804
Fuse 1 to 5 decks (amp)	16-25-32-50-63A	25-32-40-63-80A	25-40-50-80-80A	25-40-63-80-100A	25-50-63-100-125A
Power KW per deck	5	6.9	8.8	10.7	12.6

Watch the Cook On in Action
